Vertical Lathe Parameters
Item	Specification	Unit	VT45	VT65	VT75
Machining Capacity	Maximum Swing Diameter	mm	∮560	∮650	∮750
	Maximum Cutting Diameter	mm	∮450	∮600	∮700
Spindle	Spindle End Face Type		Plain	Plain	Plain
	Spindle Speed	rpm	100-2000	100-1000	100-1000
	Chuck Outer Diameter	mm	500	500	610
Tool Turret	Tool Capacity	pc	Horizontal Eight-Position	Horizontal Eight-Position	Horizontal Eight-Position
Travel	X-Axis Travel	mm	400	420	700
	Z-Axis Travel	mm	500	500	700
Hydraulic Unit	Oil Tank Capacity	L	40	40	40
	Hydraulic Motor	kw	2.2	2.2	2.2
Motor	Spindle Servo Motor	kw	15	18.5	22
Accuracy	Repetition Accuracy	mm	±0.008	±0.005	±0.005
	Positioning Accuracy	mm	±0.008	±0.008	±0.008
Machine Dimensions (LWH)	Length Width Height	mm	2200*2300*2600	2150*2210*2970	2700*2100*3200
	Weight (Including Accessories)	kg	5000	7000	9500
Power Requirements	Power Supply	3￠-AC 380V 50HZ±5%
	The machine has leakage protection and power-off protection	√
	Machine Work Status Indicator (Three-Color Light)	√
	The machine operates stably under the following conditions	Ambient Temperature 5～38°
		bient Humidity＜85%
	Machine Noise Complies with National Standards	√
Remarks	☆The equipment uses fully enclosed protection; the protective devices are safe and reliable, and should comply with GB15760-1995 General Technical Regulations for Safety Protection of Metal Cutting Machine Tools.                                                                  ☆Various hydraulic, pneumatic, and water pipe directions are marked, along with the working range of various instruments and the medium type. ☆The diameter of the hydraulic chuck and the tool turret positions can be selected according to machining requirements.

Vertical lathes are primarily used for machining large, short, heavy workpieces' external cylindrical surfaces, end faces, conical surfaces, cylindrical holes, or conical holes. They can also be equipped with auxiliary devices for threading, spherical turning, profiling, milling, and grinding. The primary characteristic of vertical lathes is that the spindle is upright, with the worktable positioned in a horizontal plane. The workpiece is clamped on a large worktable driven by the spindle's rotational motion. Due to the workpiece being mounted on a horizontal worktable, clamping is relatively convenient. The quality of the workpiece and cutting forces are supported by the rotational guide rails between the worktable and base, reducing the load on the spindle and bearings, ensuring stable operation and maintaining machining accuracy over extended periods. For more information about CNC vertical lathes, please contact us.
